Unload position
Adjustable side rails
Heavy Duty Walking Tandems Four 16,000 lb. spindles with flotation tires
Roller Bearing Deck
Roller Bearing Deck
Reinforced Lift arm
SPECIFICATIONS
| Model | Weight | Overall Height Loading Arm | Bed Height | Working Width | Shipping Width | Shipping Length | Working Length | Tire Size |
|---|---|---|---|---|---|---|---|---|
| 8/10 Bale | 10,720 lbs. | 13'3" | 48" | 12' | 103" | 26' | 32' | 520/50R 17 |
8/10 Bale Carrier
The load lift arm has a load limit of 2,500 lb.
The 8/10 Bale Carrier has a maximum load limit of 39,000 lbs. This includes the weight of the bale carrier which is approximately 11,000 lbs. Your load limit is 28,000 lbs. which would be ten, 2,500 lb. bales
| Model | Weight | Overall Height Loading Arm | Bed Height | Working Width | Shipping Width | Shipping Length | Working Length | Tire Size |
|---|---|---|---|---|---|---|---|---|
| 12/14 Bale | 12,440 lbs. | 13'3" | 50" | 12' | 104" | 31' | 37' | 520/55R 22.5 |
12/14 Bale Carrier
The load lift arm has a load limit of 2,500 lb.
The 12/14 Bale Carrier has a maximum load limit of 49,000 lbs. This includes the weight of the bale carrier which is approximately 13,000 lbs. Your load limit is 36,000 lbs. which would be fourteen, 2,500 lb. bales.
We have used other bale retrievers before and the Cloverdale is much heavier. We bought it last month and have moved about 2,500 bales so far. The best selling point is how it’s built, and it was less money.
We bought our bale carrier last month and have moved 2000 bales so far. I just moved 200 bales from three different fields in 4 hours. We love it.
